Brand Name : Eltek
Model Number : CTOS0502.nnnn
Certification : CE, UL
Place of Origin : CN
MOQ : 1 set
Price : 1800 USD / 3500 USD
Payment Terms : L/C,T/T,MoneyGram,Western Union,D/P
Supply Ability : 500 sets per month
Delivery Time : 8-10 weeks
Packaging Details : Carton pacaked
Brand : Eltek
Part No. : CTOS0502.nnnn
AC input voltage : 305Vac
DC input voltage : 300Vdc
Input Mains configuration : 230VAC Single phase;230VAC 3 phase (Δ);230/400VAC
DC output voltage : -48 VDC
DC out power : 9kw
DC output currency : 150A
Size : 132*482*300MM
Weight : 7KG
Package : cartons
Eltek Flatpack S 2U height 9KW with Flatpack S 48/1800HE 150A (CTOS0502.nnnn)
This small power dense system is purely based on pluggable breakers and rectifiers and can easily be configured to fit your required application, even in field. The combination of Flatpack S HE rectifier and Smartpack S controller ensures safe, reliable and environmental friendly operation.
The shallow depth makes it suitable for most cabinets and excellent as a replacement unit. And as it is all based on the well proven Eltek technology, the Flatpack S family is the key for future needs.
l Complete system
l SmartpackS controller
l High efficiency rectifiers
l Battery distribution
l Load distribution
l 270 mm system depth
l 2U height
l Hot pluggable rectifiers
l Hot pluggable controller
l Advanced control and monitoring through ethernet port
l 4 large breaker positions for battery and load
l 10 x 30AMCB distribution
l Push-in front connection
l LVBD
l LVLD (optional)
Parameters :
MODEL | 2BB + 2LB | 2BB + 2LB LVLD | 4BB | |||||
Part number (Configured Telecom Power system) | CTOS0502.nnnn | CTOS0502.nnnn | CTOS0502.nnnn | |||||
INPUT DATA | ||||||||
Voltage (range) | 85 to 305 VAC (45–66 Hz) / 85 to 250 VDC | |||||||
Maximum current | 21 ARMS | |||||||
Mains configuration | 3x single phase | |||||||
Connection | Rear connection on Faston connectors (6.3 mm) | |||||||
OUTPUT DATA | ||||||||
Nominal voltage | -48 VDC | |||||||
Maximum current CE | 150 ADC | |||||||
Maximum current UR (UL recognized) | 100 ADC | |||||||
BATTERY DISTRIBUTION | ||||||||
LVBD | Default | |||||||
Plug-in Breakers (max rating) | 2x 80 A | 2x 80 A | 4x 80 A | |||||
Connection | Rear connection on M6 Studs, 25 mm2 max | |||||||
LOAD DISTRIBUTION | ||||||||
LVLD (on Large Breakers) | n/a | Default | n/a | |||||
Plug-in Breakers Large (max rating) | 2x 80 A | 2x 80 A | n/a | |||||
Connection Large Breakers | Rear connection on M6 Studs, 25 mm2 max | |||||||
Plug-in Breakers Small (max rating) | 10 x 30 A 1) | |||||||
Connection Small Plug-in Breakers | Front connection Push-in terminals, 6 mm2 max | |||||||
CONTROL & MONITORING | ||||||||
Smartpack S | 6x Input / Output and Ethernet 2) | |||||||
OTHER SPECIFICATIONS | ||||||||
Dimensions (W / H / D) | 19” / 2U / 270 mm (incl. rear terminal cover) 3) | |||||||
Weight (w/o controller, rectifiers and breakers) | 6.3 kg [13.88 lbs] | |||||||
Mounting | 19” Flush mount | |||||||
Coding (prevents mixing of output voltages) | Coded for Flatpack S 48 V / 1000 W & 1800 W | |||||||
DESIGN STANDARDS | ||||||||
Electrical safety | UL60950-1 / EN60950-1 | |||||||
EMC | ETSI EN 300 386 v1.6.1 EN 61000-6-1 (immunity light industry) EN 61000-6-2 (immunity industry) EN 61000-6-3 + A1 (emission light industry) EN 61000-6-4 + A1 (emission industry) | |||||||
Environment | ETS 300 019-2-1 Class 1.2 ETS 300 019-2-2 Class 2.3 ETS 300 019-2-3 Class 3.2 Normal operating conditions as per IEC 62040-5-3:2016 clause 4.2. Other operating conditions as per IEC 62040-5-3:2016 clause 4.3, must be advised | |||||||
1) Each breaker branch (5 x B-frame breakers) rated for maximum 80 A in total 2) See Smartpack S datasheet 3) 30mm space in front and in back of the system is required for proper air flow |
